ELECTRIC WIRE ROPE HOISTS NOVA

• 250 kg (FEM/ISO: 2m/M5)
• 320 kg (FEM/ISO: 1Am/M4)

2-step, 8 or 2 m/min

Width = 379 mm

Height = 409 mm (Upper hook)

Height = 468/472 mm

Height = (Push travel trolley)

Height = 407 mm (Motor travel trolley)

Depth = 279 mm

–

• Compact design and optimum approach dimensions
• Minimum hook movement
• Lifting heights up to more than 100m
• 2-speed hoisting motors (6/1), optionally with frequency inverter for step less hoisting
• 4-step hoisting limit switch with slow-down function and phase mismatch protection
• Travelling machineries with frequency inverter, 2-speed or variation
